True Online Double Conversion
TOWER DESIGN
Digital display LCD & LED
Built-in Isolation Transformer
Wide input voltage range and frequency tolerance
Power factor 0.8
1 phase In, 1 phase Out
Multi-protections such as overload, short-circuit, over-temperature, battery under voltage, battery overcharge
Transfer time 0 ms
Crest factor 3:1
Pure sine wave output
Automatic restart
Battery cold start function
Maintenance sealed lead acid battery
Back up 15-30 mins (depend on loads)
Extension battery (Optional)
universal outlet + terminal
Software monitoring
SNMP card (optional)
TISI standards 1291-2553(1),TISI standards 1291-2553(2), TISI standards 1291-2555(3),  ISO 9001, ISO 14001, CE, EN, FCC, RoHS
​Onsite Service & PM  (According to company policy)


2 Years Warranty
Free Onsite Service at Bangkok Metropolitan Region *Conditions are as specified by the company
Pick-up and delivery of the repair product for free with express delivery.
Service Center has ISO 9001:2015


ZIRCON
The Smart Power Solution ✨
​​​​​​​
​​​​​​​

LCD Operation:
LCD control panel consists of LCD display board, LED and buttons, which displays
and controls these information including Utility, Inverter, Bypass, Load, Frequency,
Fault, Running, alarm information, function setting information.
​

ADVANCE PROTECTION FOR:
Small & medium datacenter
IT, Networking, Storage and Telecom
Infrastructure, Industrial and Medical


FEATURE
Rack/Tower Convertible Design
Patented Mimic LCD Display May be Rotated by Simply Pushing Front Button
True Online Double Conversion with DSP Control
High Output Power Factor at PF.0.9
Charger/Fan Status on the LCD Display
Green Concept Design with Superior Input
Voltage Window for Energy Saving
Hot-Swappable Battery
3-level intelligent Charging Method
Support Generator Input
Efficiency up to 90%
Estimated Remaining Time displayed on the LCD.
Support Economic(ECO) Operation Mode
Cold Start
Power Shedding May Turn Off Uncritical Load in Battery Backup
Emergency Power Off (EPO)
Frequency Converter Mode Is Settable



ZC - GP 3KVA

Input	Model Capacity (VA/W) Nominal voltage Operating voltage range Operating frequency range Power factor Max. input current(A)	ZC-GP 3KVA 3KVA /2400W 220/230Vac 165-275Vac 50/60Hz (+5%) >0.97 (with filter) 24
Output	Output voltage Output frequency Crest factor Efficiency Harmonic distortion (THD)	220Vac(+0.5%) /230Vac(+0.5%) 50/60Hz( + 0.5%) 3:1 (max) >82% <1.5%(linear load)
Battery	Battery voltage	192Vdc
SYSTEM FEATURES	Transfer time Overload Communication interface	Oms (Line mode - Battery mode) >125%: 1min, >150%: 200ms RS232, SNMP(optional), Dry contact (optional)
ENVIRONMENTAL	Operating temperature Storage temperature Humidity range Altitude Noise leve	0-40°C 25-55°C 0-95% (non-condensing) <1500m <55dB
PHYSICAL	Dimension WxDxH (mm) Net weight (S/H) (kg)	305 x 585 x 864 99/54
STANDARDS	Safety EMC	IEC/EN62040-1; IEC/EN60950-1 IEC/EN62040-2;IEC61000-4-2;1EC61000-4-3;EC61000-4-4 IEC61000-4-5;IEC61000-EMC 4-6:IEC61000-4-8



• All specifications subject to change without notice.

• Custom-made specifications are acceptable.

​​​​​​​

​​​​​​​

​​​​​​​
